LW $2, B Register 2 = value of B LW $3, C Register 3 = value of C ADD $4, $2, $3 Register 4 = B+C SW $4, A A = B + C Location LOOP_TOP is address 250 in a program - Use label LOOP_TOP instead of jump address 250 in programs SLT $1,$2,$3 If register 2 is less than register 3 then register 1=1 else register 1=0 In an assembly language flag a “1” means true and a “0” means false Used in conjunction with Bxx instruction to implement any arithmetic comparision Required for more complex assembly language If statementsġ4 MIPS Labels Instead of absolute memory addresses symbolic labels are used to indicate memory addresses in assembly language Assembly Language Programs are easier to modify and are easier to understand when labels are used Examples Variable X is stored a location 123 in memory - Use label X instead of 123 in programs.
#Iformat mips Pc
J 100 Jumps to PC+100 JAL 100 Save PC in $31 and Jumps to PC+100 Used for subroutine calls JR $31 Jumps to address in register 31 Used for subroutine returnsīEQ $1, $2, 100 If register 1 equal to register 2 jump to PC+100 Used for Assembly Language If statements BNE $1, $2, 100 If register 1 not equal to register 2 jump to PC+100 LW $1,100 Register 1 = Contents of memory location 100 Used to load registers SW $1,100 Contents of memory location 100 = Register 1 Used to save registers LUI $1,100 Register 1 upper 16-bits = 100 Lower 16-bits are set to all 0’s Used to load a constant in the upper 16-bits Other constants in instructions are only 16-bits, so this instruction is used when a constant larger than 16-bits is required for the operation R format - Uses three register operands Used by all arithmetic and logical instructions I format - Uses two register operands and an address/immediate value Used by load and store instructions Used by arithmetic and logical instructions with a constant J format - Contains a jump address Used by Jump instructionsģ2-bit Instruction Formats R, I and J OP RS RT RD SHAMT FUNCT OP RS RT Address/Immediate OP Jump Addressĥ MIPS Instruction Set Only Load instruction can read an operand from memory Only Store instruction can write an operand to memory Typcial RISC calculations require Load(s) to get operands from memory into registers Calculations performed only on values in registers Store(s) to write result from register back to memoryĦ MIPS Addressing Modes Register - Uses value in register as operandĮxample $2 - Uses register 2 as operand Direct Address - Uses value stored in memory at given address Example Uses value stored at location 100 in memory as operand Register Indirect Address - Uses value in register as address of operand in memory Example ($3) - Uses value in register 3 as address of memory operandħ MIPS Addressing Modes Indexed Address - Adds address field and register value and uses this as address of operand in memory Example ($2) - Adds 100 to the value in register 2 and reads the operand from the resulting memory address Used for array X operations, the array index is normally in the register and the address field is the first location in the arrayĨ MIPS Addressing Modes Immediate Addressing - Uses constant value contained in instruction Example addi $1,$2,4 - adds constant 4 to register 2 and stores result in register 1 Used for constants in programs PC relative - Address from instruction is added to the current value in the Program Counter Example J Jumps to address PC+4 Saves address bits in jump instructionsĪDD $1,$2,$3 Register 1 = Register 2 + Register 3 SUB $1,$2,$3 Register 1 = Register 2 - Register 3 AND $1,$2,$3 Register 1 = Register 2 AND Register 3 ADDI $1,$2,10 Register 1 = Register SLL $1, $2, 10 Register 1 = Register 2 shifted left 10 bits Pipelined Execution of Instructions All instructions are 32-bits Most Instructions executed in one clock cycle bit memory words Byte addressable memory A 32-bit word contains four bytes To address the next word of memory add 4
#Iformat mips simulator
Typical of Modern RISC Instruction sets Free Simulator Available for Unix, PCs and Macs Used in real machines - MIPS R2000 Processors Used in many CS Compiler Classes as Target MachineĢ MIPS Architecture 32-bit RISC Processor 32 32-bit Registers, $0.$31
